Introduction
-

                  -
            Program the board with the code in "Perfect Cell - Autosampler Testing"
-
            Programming the board this way bypasses the modem and allows for automatic triggering upon resetting the open storm board without the use of the autosampler

-

-

                  -
            Open Saleae Logic Analyzer. Then, connect the Logic Analyzer to the computer using USB
-
            To ensure that the Logic Analyzer is connected to the computer, you should see a message at the top of the Saleae Logic Analyzer that says [Connected]. There should also be a blinking light coming from the Logic Analyzer (the light pictured is green, though any light emitting from the Logic Analyzer means it is connected)

-

-

                  -
            Connect one of the probes (the colored wires attached to the Logic Analyzer) to the end of one of the headers (the piece of black plastic)
-
            Once the probe is connected to the header, pull down on the header. Two small wires will come out
-
            Keeping the header pulled down, attach the two wires at the end of the header to the desired wire to be tested

-

To reassemble your device, follow these instructions in reverse order.
