Background

The Alienware m15 R6 is a gaming laptop released by Dell in 2021, part of Alienware’s m-series lineup. It features a sleek design and is built with components aimed to deliver gaming capabilities in a portable form factor.

The laptop is powered by NVIDIA GeForce RTX 30 series graphics and Intel’s 11th Gen Core processors. It includes a customizable RGB keyboard and advanced cooling system.

The m15 R6 can be identified by its model number P109F and specific design elements, including the Alienware logo and a thin-bezel display.

Identification

The Alienware m15 R6 can be easily identified by its unique design and specific model number. Key identifying features include:

  • Model Number: The model number P109F is printed on a label located on the underside of the laptop.
  • Logo and Branding: The laptop features the iconic Alienware alien head logo on the lid, which illuminates when powered on. The Alienware logo also appears on the keyboard deck above the keyboard.
  • Display and Bezel: The m15 R6 has a 15.6-inch display with thin bezels, creating an immersive viewing experience. This model typically comes with options for a high refresh rate display, including 165Hz and 240Hz versions, catering to fast-paced gaming.
  • Chassis Design: The m15 R6 features a sleek, matte black finish with customizable RGB lighting on the keyboard and a light-up Alienware logo on the lid. The rear of the chassis has a distinctive exhaust vent design that enhances airflow and cooling.
  • Keyboard and Ports: The laptop includes a customizable RGB backlit keyboard and various ports, including USB-A, USB-C, HDMI, and an Ethernet port, placed along the sides and back.

Technical Specifications

  • Processor:
    • Intel Core i7-11800H or Intel Core i9-11900H (8 cores, 16 threads, up to 4.6 GHz turbo)
  • Graphics:
    • NVIDIA GeForce RTX 3060, RTX 3070, or RTX 3080 (depending on configuration)
  • Memory:
    • 16GB DDR4 3200MHz (expandable to 32GB)
  • Storage:
    • 512GB PCIe M.2 SSD (upgradable to 1TB or 2TB)
  • Display:
    • 15.6-inch Full HD (1920x1080) or QHD (2560x1440), up to 240Hz refresh rate, 3ms response time
    • Optional: Dolby Vision support for HDR
  • Battery:
    • 86Wh battery, up to 8 hours of usage (depending on configuration and usage)
  • Operating System:
    • Windows 10 Home or Windows 10 Pro (depending on configuration)
  • Ports:
    • 1 x USB 3.2 Type-C with Power Delivery and DisplayPort 1.4
    • 3 x USB 3.2 Type-A
    • 1 x HDMI 2.1
    • 1 x Ethernet (RJ45)
    • 1 x SD Card reader
  • Audio:
    • Stereo speakers with Nahimic 3D Audio
  • Wi-Fi:
    • Killer Wi-Fi 6 AX1650 (2x2)
  • Keyboard:
    • 4-zone RGB AlienFX customizable lighting
  • Cooling:
    • Alienware Cryo-Tech cooling technology with dual-fan cooling system
